Precision Fixation for Small Bone Fractures

At OrthoPro, we specialize in delivering high-performance orthopedic solutions to healthcare providers and distributors worldwide. The 2.7mm Mini T-Locking Plate (2 Holes Head) is a cornerstone of our Small Fragment System. It is specifically engineered to address the challenges of fractures near joints in small bones, where space is limited and soft tissue coverage is thin.

This orthopedic implant combines the mechanical advantages of locking screw technology with an anatomical T-shape design. This configuration is crucial for capturing small bone fragments in the metaphysis while providing a stable shaft for diaphyseal fixation. Whether utilized for hand surgery or foot and ankle reconstruction, this plate offers the reliability surgeons demand.

Key Features and Surgical Benefits

The 2.7mm Mini T-Locking Plate is designed with the surgeon’s needs in mind, focusing on ease of use and optimal clinical outcomes:

• Anatomical T-Shape Design: The 2-hole head configuration allows for the clustering of screws in the peri-articular zone, providing excellent buttressing against collapsing forces in intra-articular fractures.
• Low-Profile Architecture: With rounded edges and a polished surface, the plate minimizes tendon irritation and reduces the risk of soft tissue impingement, which is critical in areas like the dorsal hand or foot.
• Locking & Compression Capability: The combi-holes in the plate shaft allow for the use of 2.7mm locking screws for angular stability or 2.7mm cortical screws for dynamic compression, offering intraoperative versatility.
• Tapered Tip: The end of the plate is tapered to facilitate minimally invasive sub-muscular insertion, preserving the periosteal blood supply.

Material Excellence

Quality and biocompatibility are non-negotiable at OrthoPro. Our Mini T-Locking Plate is manufactured from premium medical-grade materials to ensure structural integrity and patient safety:

Titanium Alloy (Ti-6Al-4V): Preferred for its high strength-to-weight ratio, excellent biocompatibility, and MRI compatibility.

Stainless Steel (316LVM): Known for its superior mechanical strength and cost-effectiveness in trauma reconstruction.

Technical Specifications

Our **2.7mm Mini T-Locking Plate** adheres to strict dimensional tolerances to ensure compatibility with standard 2.7mm instrument sets. Below are the detailed parameters:

Clinical Indications

The **2.7mm Mini T-Locking Plate** is indicated for the operative treatment of fractures, osteotomies, and non-unions of small bones. Specific applications include:

• Hand: Metacarpal neck and head fractures, proximal and middle phalanx fractures.
• Wrist: Distal radius fractures (volar or dorsal approach) and distal ulna fractures.
• Foot: Metatarsal fractures and tarsal bone fixation.
• Pediatrics: Long bone fractures in small pediatric patients where a 3.5mm system is too large.

Why Partner with OrthoPro?

As a dedicated B2B supplier, OrthoPro understands the logistics and quality requirements of the global medical device market. We provide comprehensive support to distributors and hospital purchasing departments, ensuring that you receive high-quality implants at competitive prices.

Our manufacturing processes are ISO-certified, ensuring that every T-locking plate meets international standards for safety and performance. We maintain a robust inventory to support rapid order fulfillment.
